singleloopcontrollermaxvu16

The new MAXVU is a cost effective temperature controller which is fast to configure, has improved display visibility and reduces costs by minimising wiring and panel space.

•18mm upper and 10.2mm lower display digits

•‘Heat’ only or ‘heat & cool’ strategy

•2 alarms (absolute, deviation, band, loop)

•Latching or non-latching alarm outputs

•Zero shift or 2 point calibration

•Ramp/dwell with delay time

•3 tactile keys

•Front keys or software programming

•Integral configuration port

Product Category:

Dimensions and size:

Primary Input Type:

Output Type:

Max. Number of Outputs:

Weight:

Temperature and RH::

Power Supply:

Front Panel Protection:

Certifications:

Compliance:

Communications:

Temperature and Process Controller

48mm x 48mm x 67mm (HxWxD), 1/16 DIN

Thermocouple (J,K,C,R,S,T,B,L,N), RTD (3 Wire PT100),

DC Linear (0 to 20mA, 4 to 20mA, 0 to 50mV, 10 to 50mV, 0 to 5V, 1 to 5V, 0 to 10V, 2 to 10V.)

Relay, SSR

2 or 3

0.1kg excluding packaging

0 to 55°C (-20 to 80°C storage), 20% to 95% RH non-condensing

100 to 240V 50/60Hz +/- 10% (mains powered version)

24V DC/AC +10%/-15%, AC 50/60Hz (low voltage version)

IP65 (Behind panel IP20)

CE, UL & cUL

Complies with EN61326 (Susceptibility & Emissions)

Complies with EN61010-1

Pollution Degree 2, Installation Category II

RS485 Modbus RTU communication option
